Multi Head Embroidery Machine
1. Original Dahao New Touch Screen:
Models: A18 / A58 / A68 / A8 Mate Smart Computer
Features: Available with or without Motorized Trimmer and.... Read More
with UTC (Under Tension Control)
2. Dahao Servo Motor:
Main Shaft and X Y Movement with Fan Cooling System
Configuration: Triple Servo System
3. Embroidery Area:
Available Sizes: 200mm, 300mm, 400mm, 500mm, and customizable options
4. Colour/Needles:
Options: 6/9/12/15 needles
5. Pantograph/Frame Width:
Sizes: 1000mm, 1200mm, 1300mm, 1400mm, 1500mm, 1600mm, 1700mm
6. Number of Heads:
Configurations: 1/2/3 to 15/18/20/23/30…….176 heads
7. Japanese Jumbo Black Coated High-Speed Hooks:
Sizes: 1.6mm / 1.0mm
8. High-Speed Head:
Features: Double Cam Triple Lever System
9. Pressure Foot System:
Options: Independent Motorized or Normal Pressure Foot System
10. Jump Motor System:
Availability: With jump motor for handling long stitch designs and long life.
11. Barudan Type Tension Base:
Additional Feature: Piping System
12. Auto Oiling System:
Ensures smooth operation and reduces maintenance needs
13. Machine Body:
Size: 400x400x12mm, 400x550mmx12mm, 300x400mmx10mm, 300x300mmx10mm, heavy body
Back Side Supports: 3 pcs, variable according to the model
14. Table Quality:
Material: High-Quality Table with High-Processed White Color Mica
15. Lights:
Thread Stand with Lights for enhanced visibility
16. Z-Drive System:
New Type Z-Drive System for both side alternate
17. Spare Parts and Accessories:
Standard spare parts and accessories included
Note:
Specifications are subject to customization based on specific model requirements.
These specifications highlight the advanced features and options available in the Flat Head Embroidery Machine, ensuring high performance, precision, and versatility in embroidery applications.
